Long Muffle Lifespan , High Temperature Brazing Furnace, Mesh-Belt Transfer
Overview
It is mainly used for continuous brazing of stainless steel pieces, copper pieces, steel pieces and other materials under the protective atmosphere, particularly applicable to various parts of refrigeration, compressor refrigerator and microwave oven parts, auto parts, electronic plug, tools and hardware tools, etc.
The furnace adopts mesh belt to transfer brazing parts through heating furnace and cooling zone. The inert gas or ammonia dissociated gas is used as the protective gas in the furnace to prevent and avoid the oxidation of workpiece during heating and brazing.
The heating furnace (also known as furnace liner) is made of durable fireproof stainless steel and the cooling zone is equipped with circulating cooling water jacket.
Continuous protective atmosphere brazing furnace adopts reasonable heating structure and uniform temperature.The workpiece runs smoothly on the conveyor belt and has little deformation.
High Temperature Brazing Furnace Parameter
| Model | RCWE12- 35×350×20 | RCWE12- 40×350×24 | RCWE12- 42×350×30 | ||
| Rated Power | 100 | 110 | 120 | ||
| Max Operating Temperature | 1150 | 1150 | 950 | ||
| Belt Width(mm) | 350 | 400 | 420 | ||
Work Zone (W×L×Hmm) | 390×3500×200 | 450×3500×245 | 460×3500×300 | ||
| Protective Atmosphere | Exothermic, Dissociated Ammonia, Mixed Nitrogen Hydrogen, Pure Hydrogen | ||||
About us
Started in early 1990’s Xi’an Aojie designed and manufactured its
first mesh-belt controlled atmosphere continuous brazing furnace.
In the years that have followed, Xi’an Aojie has committed to
independent research and development of advanced brazing furnaces
and heat treat equipments. Nowadays, Aojie mesh-belt continuous
controlled atmosphere brazing furnace has successfully replaced
imported equipment due to its unique advantages. Aojie mesh-belt
controlled atmosphere brazing furnaces are widely used for brazing
parts of stainless steel, carbon steel, aluminum, brass and copper,
etc. by the industries of automobile, aero-space & aviation, and
household appliances, etc.
Xi’an Aojie is a full service supplier, beginning with initial
technical services such as feasibility studies, facility analysis
and planning, continuing through equipment manufacturing, system
installation, furnace start-up and operator training.
Aojie is always untiringly seeking to provide dependable equipment and technical support for customers to manufacture high-quality and low-cost products.
|
|
