Continous , Aluminum Brazing Furnace , Controlled Atmosphere , Refractory Material

Overview

Under the effect of nitrogen protection, the equipment uses non-corrosive brazing agent to continuously braze aluminum medium cooler tank, automobile air conditioning condenser, evaporator, heater fan tank, aluminum oil cooler and other products etc.

Features

• Fire- resistant materials are adopted to ensure the superior insulation feature of the furnace with low energy consumption while empty load.
• The excellent designing and manufacturing of the gas distribution system and atmosphere curtain of the furnace ensure the low consumption of purified nitrogen and save the furnace atmosphere so as to decrease the production cost.
• The heating zone is good arranged, and the temperature control meters is very effective with high precision which guarantee the temperture at a rather stable level with little difference when brazing.
• Advanced frequency conversion mesh-belt speed control system realizes stepless speed change transmission and precise control runtime of workpieces in each heating zone so as to realize the precise heating curve of aluminum brazing.
• High precision oxygen analyzer has provided an advanced means for measuring the atmosphere of the aluminum brazing furnace timely and accurately.
• The spray fluxer has the features of compact in design and straightforward operation. The spray nozzle insures adequate spray on the workpieces. Air blower insures the extra flux can be blew off.

Aluminum Brazing Furnace Parameters

Xi'an Aojie Electric Heating Equipment Engineering Co., Ltd. is a premier manufacturer of mesh-belt controlled atmosphere continuous brazing furnaces and industrial heat treat systems.

Started in early 1990s, Xi'an Aojie designed and manufactured its first mesh-belt controlled atmosphere continuous brazing furnace. In the years that have followed, Xi'an Aojie has committed to independent research and development of advanced brazing furnaces and heat treat equipments.

Nowadays, Aojie mesh-belt continuous controlled atmosphere brazing furnace has successfully replaced imported equipment due to its unique advantages. Aojie mesh-belt controlled atmosphere brazing  furnaces are widely used for brazing parts of stainless steel, carbon steel, aluminum, brass and copper, etc. by the industries of automobile, aero-space & aviation, and household appliances, etc.

To serve the aero-space & aviation industry, Aojie developed high, intermediate and low temperature high precision electric heating car bottom furnaces which meet temperature uniformity requirements set by US Military Specifications.

Aojie also developed BAB production lines for the production of stators and rotors of high efficiency and power economized motors.

Xi'an Aojie is a full service supplier, beginning with initial technical services such as feasibility studies, facility analysis and planning, continuing through equipment manufacturing, system installation, furnace start-up and operator training.

Aojie is always untiringly seeking to provide dependable equipment and technical support for customers to manufacture high-quality and low-cost products.

Some of our customers are as follows:
